PART NO. THREAD DIMENSIONS E F A L S1 5JN-04-02 7/16"X20 Z1/8"X27 14 30.2 17 5JN-04 7/16"X20 Z1/4"X18 14 35.5 19 5JN-05-04 1/2"X20 Z1/4"X18 14 35.3 19 5JN-06-04 9/16"X18 Z1/4"X18 14.1 35.6 19 5JN-06 9/16"X18 Z3/8"X18 14.1 37.1 22 5JN-06-08 9/16"X18 Z1/2"X14 14.1 42.5 30 5JN-08-06 3/4"X16 Z3/8"X18 16.7 39.6 22 5JN-08 3/4"X16 Z1/2"X14 16.7 45.6 30 5JN-08-12 3/4"X16 Z3/4"X14 16.7 45 36 5JN-10-08 7/8"X14 Z1/2"X14 19.3 48 30 5JN-10-12 7/8"X14 Z3/4"X14 19.3 49.7 36 5JN-12-08 1.1/16"X12 Z1/2"X14 21.9 52.1 30 5JN-12 1.1/16"X12 Z3/4"X14 21.9 52.3 36 5JN-16-12 1.5/16"X12 Z3/4"X14 23.1 50 36 5JN-16 1.5/16"X12 Z1"X11.5 23.1 59.7 41 5JN-20 1.5/8"X12 Z1.1/4"X11.5 24.3 61.5 50 5JN-24 1.7/8"X12 Z1.1/2"X11.5 27.5 62.5 60 5JN-32 2.1/2"X12 Z2"X11.5 33.9 70 70
Pehel | P5JN | Hydraulic JIC Male 74° Cone / NPT Female Hose Adapter
PEHEL Hydraulic Model: P5JN
QTY:
Material: Carbon steel
Brand: Pehel
Color: Silver
OEM Designed: Yes
Surface Treatment: Zinc Plated
Thread: JIC/NPT
About the item:
1.Multi-standard hose fitting – connects JIC and NPT systems with ease.
2. Reliable hose adapter – bridges JIC male to NPT female ports seamlessly.
3. Precision JIC adapter – meets SAE J514 standards for leak-free flare sealing.
4. Built-in reducer – allows step-down from larger JIC to smaller NPT connections.
5. Durable steel body – corrosion-resistant for high-pressure hydraulic applications.
