THREAD DIMENSIONS PART NO. E TUBE O.D. B D L S1 2WJ-10-04 7/16"X20 10 9.5 10 25.5 17 2WJ-12-05 1/2"X20 12 9 12 27 19 2WJ-14-04 7/16"X20 14 9.5 14 27 17 2WJ-14-06 9/16"X18 14 9.5 14 55 19 2WJ-18-08 3/4"X16 18 10.8 18 60 24 2WJ-20-10 7/8"14 20 12 20 33 27 2WJ-22-12 1.1/16"X12 22 13 22 68 32 2WJ-28-16 1.5/16"X12 28 14 28 68 41 2WJ-34-20 1.5/8"X12 34 15 34 75 50
PEHEL/BUTT-WELD TUBE / JIC FEMALE 74° SEAT ADAPTER
PEHEL Hydraulic Model: P2WJ
QTY:
BUTT-WELD TUBE / JIC FEMALE 74° SEAT ADAPTER
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type 1: BUTT-WELD TUBE
Thread Type 2: JIC FEMALE 74° SEAT
About the item:
1. Butt-Weld Tube / JIC Female 74° Seat — weld-on adapter with JIC female thread and 74° cone seat.
2. Butt-weld tube end provides a strong, permanent, leak-tight connection to tubing.
3. JIC female thread (UNF) accepts standard JIC male 74° cone fittings.
4. Available for tube O.D. from 10 to 34 mm with 7/16"-20 to 1-5/8"-12 threads.
5. Ideal for hydraulic and pneumatic systems requiring welded tube-to-JIC connections.
