THREAD TUBE O.D. DIMENSIONS PART NO. E F D A B L S1 S2 1QT-10-02SP M10X1 R1/8"X28 5 12 10 28 12 14 1QT-14-04SP M14X1.5 R1/4"X19 8 17 14.5 37.5 17 17 1QT-14-06SP M14X1.5 R3/8"X19 8 17 15 38 17 17 1QT-16-04SP M16X1.5 R1/4"X19 10 18 14.5 38.5 17 22 1QT-16-06SP M16X1.5 R3/8"X19 10 18 15 39 17 22 1QT-18-04SP M18X1.5 R1/4"X19 12 18 14.5 38.5 19 24 1QT-18-06SP M18X1.5 R3/8"X19 12 18 15 39 19 24 1QT-22-08SP M22X1.5 R1/2"X14 14 19.5 20 47.5 24 27 1QT-27-08SP M27X1.5 R1/2"X14 18 20 20 50 30 32 1QT-27-12SP M27X1.5 R3/4"X14 18 20 20 50 30 32 1QT-30-12SP M30X1.5 R3/4"X14 20 23 20 53.5 32 36 1QT-33-12SP M33X2 R3/4"X14 22 26 20 57 36 38 1QT-36-16SP M36X2 R1"X11 25 26 25.5 61.5 38 41 1QT-39-16SP M39X2 R1"X11 28 26 25.5 64.5 41 46 1QT-45-20SP M45X2 R1.1/4"X11 34 28.5 26.5 68 46 55
Pehel/1QT/High Quality Male Metric 74° Cone-Male BSPT Straight Adapter
PEHEL Hydraulic Model: P1QT-SP
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: elbow
Thread Type: NPT/BSP 60° Cone
About the item:
1.Precision-machined straight hydraulic adapters with concentric thread alignment, eliminating flow turbulence and pressure drop in high-flow hydraulic loops.
2.Interchangeable with ISO 8434 standard counterparts, no custom modification required for direct replacement in existing hydraulic systems.
3.Zinc-plated carbon steel body with salt spray resistance up to 240 hours, effectively preventing corrosion in outdoor and humid working environments.
