THREAD TUBE O.D. DIMENSIONS PART NO. E F D A B S1 S2 1QN4-12-02 M12X1.5 Z1/8"X27 6 23 17 11 14 1QN4-14-02 M14X1.5 Z1/8"X27 8 26 18 14 17 1QN4-14-04 M14X1.5 Z1/4"X18 8 26 21 14 17 1QN4-16-06 M16X1.5 Z3/8"X18 10 24 24 16 22 1QN4-18-06 M18X1.5 Z3/8"X18 12 28 24 19 24 1QN4-22-08 M22X1.5 Z1/2"X14 14 30.5 29.5 22 27 1QN4-27-08 M27X1.5 Z1/2"X14 18 33 31 27 32 1QN4-27-12 M27X1.5 Z3/4"X14 18 33 35 27 32 1QN4-30-12 M30X1.5 Z3/4"X14 20 36.2 35.5 30 36 1QN4-36-16 M36X2 Z1"X11.5 25 42 41 36 41 1QN4-39-16 M39X2 Z1"X11.5 28 44.5 42.5 41 46 1QN4-45-20 M45X2 Z1.1/4"X11.5 32 47 43 41 50
45° Elbow | Metric Male 74° Cone x NPT Male Adapter
PEHEL Hydraulic Model: P1QN4/P1QN4-RN
QTY:
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: elbow
Thread Type: Metric NPT
Surface Treatment: CR3+ White Zinc Plated
About the item:
1.Dual Thread Conversion: This 45° elbow seamlessly bridges metric male 74° cone systems with NPT male threads, solving cross-standard connection challenges in mixed hydraulic setups.
2.Precision 74° Cone Seal: The machined 74° cone face creates a metal-to-metal seal that withstands extreme pressures, eliminating leaks without requiring O-rings or gaskets.
3.Space-Saving 45° Angle: The moderate 45-degree bend allows flexible routing of hydraulic lines in tight spaces while reducing flow restriction compared to sharper elbows.
4.Dual Material Options: Choose carbon steel for high-strength industrial use or stainless steel for superior corrosion resistance in chemical or marine environments.
5.OEM Quality Assurance: Manufactured as an OEM cone seal connector, each elbow meets strict thread and angle tolerances for reliable, repeatable performance across installations.
