PART NO. THREAD O-RING DIMENSIONS E F F A B L S1 1JG-04-02 7/16"X20 G1/8"X28 O011 14 9.5 32 14 1JG-04 7/16"X20 G1/4"×19 O111 14 11 32.5 19 1JG-04-06 7/16"X20 G3/8"×19 O113 14 11.5 34 22 1JG-04-08 7/16"X20 G1/2X14 O115 14 14 39 27 1JG-05-04 1/2X20 G1/4""X19 O111 14 11 33 19 1JG-05-06 1/2"×20 G3/8"×19 O113 14 11.5 36 22 1JG-05-08 1/2"x20 G1/2"X14 O115 14 14 39 27 1JG-06-04 9/16"X18 G1/4"X19 O111 14.1 11 32.5 19 1JG-06 9/16"X18 G3/8"×19 O113 14.1 11.5 34 22 1JG-06-08 9/16X18 G1/2"X14 O115 14.1 14 39 27 1JG-08-04 3/4"X16 G1/4"X19 O111 16.7 11 36 22 1JG-08-06 3/4"X16 G3/8""x19 O113 16.7 11.5 37 22 1JG-08 3/4"X16 G1/2"X14 O115 16.7 14 42 27 1JG-08-12 3/4"x16 G3/4"X14 O119 16.7 15.5 44 32 1JG-10-06 7/8"X14 G3/8"×19 O113 19.3 11.5 40.5 24 1JG-10-08 7/8"X14 G1/2"X14 O115 19.3 14 44.5 27 1JG-10-12 7/8"X14 G3/4""X14 O119 19.3 15.5 48.5 32 1JG-12-08 1.1/16"X12 G1/2"X14 O115 21.9 14 49 30 1JG-12 1.1/16""X12 G3/4""X14 O119 21.9 15.5 49.5 32 1JG-12-16 1.1/16"X12 G1"X11 O217 21.9 18 54 41 1JG-12-20 1.1/16"X12 G1.1/4"X11 O222 21.9 20 57 50 1JG-16-12 1.5/16"X12 G3/4""X14 O119 23.1 15.5 52.5 36 1JG-16 1.5/16"X12 G1"X11 O217 23.1 18 55 41 1JG-16-20 1.5/16"X12 G1.1/4"X11 O222 23.1 20 58 50 1JG-20-16 1.5/8"X12 G1"X11 O217 24.3 18 58 46 1JG-20 1.5/8""X12 G1.1/4"X11 O222 24.3 20 59.5 50 1JG-24-16 1.788""X12 G1"X11 O217 27.5 18 63.5 50 1JG-24-20 1.7/8""×12 G1.1/4""X11 O222 27.5 20 65.5 50 1JG-24 1.788"X12 G1.1/2"X11 O224 27.5 21.5 64 55
PEHEL | JIC 74° Male x BSP Male O-Ring Hydraulic Adapter, Male-to-Male Threaded Fitting
PEHEL Hydraulic Model: 1JG
QTY:
Type: JIC Male to BSP Male O-Ring Adapter
End 1: JIC Male 74° Cone
End 2: BSP Male (BSPP) with O-Ring
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc-plated or anti-rust coated
About the item:
1.JIC male 74° cone to BSP male O-ring hydraulic adapter, designed for transitioning between JIC 74° cone connections and BSP male ports with O-ring sealing.
2.JIC male end features a 74° cone seat for metal-to-metal sealing, providing reliable leak-proof performance under high pressure.
3.BSP male end includes an integrated O-ring for sealing against BSPP female ports, eliminating the need for thread sealant.
4.Manufactured from high-strength carbon steel with anti-rust surface treatment for excellent durability and corrosion resistance.
5.Precision machined threads and sealing surfaces ensure consistent fit and reliable sealing in hydraulic systems.
