THREAD OO-RING DIMENSIONS PART NO. E F G G A B C S1 S2 ASSG-02OG G1/8"X28 G1/8"X28 G1/8"X28 O011 21.8 21.8 27 11 14 ASSG-04OG G1/4"X19 G1/4"X19 G1/4"X19 O111 28 28 31 14 19 ASSG-06OG G3/8"X19 G3/8"X19 G3/8"X19 O113 29 29 35.5 16 22 ASSG-08OG G1/2"X14 G1/2"X14 G1/2"X14 O115 38 38 43.5 22 27 ASSG-12OG G3/4"X14 G3/4"X14 G3/4"X14 O119 43 43 49.5 27 32 ASSG-16OG G1"X11 G1"X11 G1"X11 O217 48.5 48.5 54.5 33 41 ASSG-20OG G1.1/4"X11 G1.1/4"X11 G1.1/4"X11 O222 57 57 59 41 50 ASSG-24OG G1.1/2"X11 G1.1/2"X11 G1.1/2"X11 O224 61 61 65 48 55
PEHEL | JIS Gas Male 60° Cone Adapter | High-Pressure Fitting
PEHEL Hydraulic Model: PASSG-OG
QTY:
Material: Carbon steel, Stainless Steel, Aluminium, Brass
Brand: Pehel, OEM
Color: Silver
Connector Type: Tee
Thread Type: Hydraulic Hose Adapter
1. Reliable sealing performance, resistant to leakage under high pressure conditions
2. High pressure bearing capacity, compatible with multi circuit hydraulic systems
3. High precision insert, smooth oil flow with low pressure drop
