THREAD O-RING DIMENSIONS PART NO. E F G F A B C S1 AKHK-14-12-14OG M14X1.5 M12X1.5 M14X1.5 O09.3X2.4 25.5 33.5 25.5 14 AKHK-14OG M14X1.5 M14X1.5 M14X1.5 O11.3X2.4 27.5 32 27.5 14 AKHK-16-14-16OG M16X1.5 M14X1.5 M16X1.5 O11.3X2.4 28.5 35.5 28.5 16 AKHK-18-14-18OG M18X1.5 M14X1.5 M18X1.5 O11.3X2.4 30.8 37.5 30.8 19 AKHK-18-16-18OG M18X1.5 M16X1.5 M18X1.5 O13.3X2.4 30.8 39.5 30.8 19 AKHK-18-20-18OG M18X1.5 M20X1.5 M18X1.5 O17.3X2.4 30.8 44 30.8 19 AKHK-20-18-20OG M20X1.5 M18X1.5 M20X1.5 O15.3X2.4 33 42.5 33 19 AKHK-22-20-22OG M22X1.5 M20X1.5 M22X1.5 O17.3X2.4 35 45.5 35 22 AKHK-24-20-24OG M24X1.5 M20X1.5 M24X1.5 O17.3X2.4 40 47 40 24 AKHK-24-22-24OG M24X1.5 M22X1.5 M24X1.5 O19.3X2.4 40 47 40 24 AKHK-30-27-30OG M30X1.5 M27X2 M30X1.5 O23.5X3.0 48 57 48 30 AKHK-33OG M33X1.5 M33X2 M33X1.5 O29.5X3.0 54.5 59 54.5 33
Pehel/AKHK-OG/JIS Metric Male 60° Cone-Metric Flat O-Ring seal-Male Metric JIS 60° Cone Adjustable Tee Connector
PEHEL Hydraulic Model: PAKHK-OG
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: Tee
Thread Type: JIS metric 60 cone/Metric flat o-ring seal
About the item:
1.JIS standard 60° cone design delivers zero-leak sealing under high pressure hydraulic working conditions
2.Adjustable tee structure allows flexible piping layout for complex fluid system installation
3.Precision machined metric port with flat O-ring ensures consistent sealing performance for long-term operation
4.High-tensile carbon steel body offers excellent corrosion resistance and extended service life in harsh environments
