PART NO. FLANGE SIZE DXt DIMENSION MPa d1 D l L 3000PSI 1FLW-08-16X2 1/2” 16X2 30.2 16 6.8 41 34.5 1FLW-08-20X2.5 1/2” 20X2.5 20 1FLW-12-25X3 3/4” 25X3 38.1 25 6.8 50 1FLW-16-25X3 1” 25X3 44.4 25 8 50 1FLW-16-28X3 1” 28X3 28 1FLW-16-30X4 1” 30X4 30 1FLW-16-38X5 1” 38X5 38 1FLW-20-25X3 1.1/4” 25X3 50.8 25 8 55 27.6 1FLW-20-30X4 1.1/4” 30X4 30 1FLW-20-38X5 1.1/4” 38X5 38 1FLW-20-42X6 1.1/4” 42X6 42 1FLW-24-38X4 1.1/2” 38X4 60.3 38 8 57 20.7 1FLW-24-42X5 1.1/2” 42X5 42 1FLW-24-45X5 1.1/2” 45X5 45 1FLW-24-50X6 1.1/2” 50X6 50 1FLW-32-55X5 2” 55X5 71.4 55 9.6 57 1FLW-32-60X8 2” 60X8 60 1FLW-40-65X6 2.1/2” 65X6 84.1 65 9.6 58 17.2 1FLW-40-70X7.5 2.1/2” 70X7.5 70 1FLW-48-80X6 3” 80X6 101.6 80 9.6 58 13.8 1FLW-48-90X8 3” 90X8 90 6000PSI1FSW-08-16X2 1/2” 16X2 31.7 16 7.8 34 40 1FSW-08-20X2.5 1/2” 20X2.5 20 1FSW-12-16X2 3/4” 16X2 41.3 16 8.8 38 1FSW-12-20X2.5 3/4” 20X2.5 20 1FSW-12-25X4 3/4” 25X4 25 1FSW-16-25X3 1” 25X3 47.6 25 9.5 40 1FSW-16-30X4 1” 30X4 30 1FSW-16-38X5 1” 38X5 38 1FSW-20-25X3 1.1/4” 25X3 54 25 10.3 45 1FSW-20-30X4 1.1/4” 30X4 30 1FSW-20-38X5 1.1/4” 38X5 38 1FSW-20-42X6 1.1/4” 42X6 42 1FSW-24-38X5 1.1/2” 38X5 63.5 38 12.6 50 1FSW-24-45X6.5 1.1/2” 45X6.5 45 1FSW-24-48X8 1.1/2” 48X8 48 1FSW-24-50X8 1.1/2” 50X8 50 1FSW-32-60X8 2” 60X8 79.4 60 12.6 58 1FSW-32-60X10 2” 60X10 60
SAE Flange/weld Tube
PEHEL Hydraulic Model: 1FLW-1FSW
QTY:
