heavy tube clamp; DIN3015 standard
Clamp size Hexagon head bolt
(GB5782-86)
d×1Socket head screws
(GB70-85)
d×1Stacking bolts Loking palte Order code size Order code size a b m sw a b s d e 1 M10×45
M10×45 PTH-H1 25 51 M10 15 PTH-L1 55 33 8 14 15.5 2 M10×60 M10×60 PTH-H2 40 66 M10 15 PTH-L2 70 30 8 26 15.5 3 M10×70 M10×70 PTH-H3 52 78 M10 15 PTH-L3 85 30 8 41 15.5 4 M12×100 M12×100
PTH-H4 85 112 M12 17 PTH-L4
115 45 10 69 17.55 M16×130
M16×130
PTH-H5 110 146 M16 21 PTH-L5 152 60 10 69 17.5 6 M20×190 M20×190 PTH-H6 153 206 M20 27 PTH-L6 205 80 15 135 27.5 7 M24×220 M24×220 PTH-H7 185 245 M24 30 PTH-L7 250 90 15 169 30.5 8 M30×300 M30×300 PTH-H8 250 330 M30 36 PTH-L8 320 120 25 219 36.5
DIN3015 Heavy Duty Tube Clamp - Carbon & Stainless Steel Hydraulic Pipe Hose Clamp
PEHEL Hydraulic Model: Heavy Tube Clamp PTH-H1-PTH-L1
QTY:
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Surface Treatment: CR3+ White Zinc Plated
Bolts: Grade 4.8 or 8.8
About the item:
1.Engineered strictly to the DIN3015 standard, ensuring universal compatibility and reliable heavy-duty performance for your hydraulic systems.
2. Available in premium carbon steel and stainless steel variants to meet diverse environmental and pressure requirements.
3. Features a superior silver color zinc plating finish, providing exceptional corrosion and rust resistance for extended service life.
4. As a robust heavy duty tube clamp, it effectively absorbs vibration and noise in high-pressure hydraulic and pneumatic pipelines.
5.The ultimate hydraulic pipe hose clamp solution, designed for quick installation and secure fastening of tubes, pipes, and hoses.
