heavy tube clamp; DIN3015 standard
Clamp size Weld plate Double weld plate Weld/screw plate Order code clamp size Order code Size Order code Size d f g s m d f g s m d g f s k n m 1 PTH-A1
33 30 73 8 M10 PTHD-A1 33 60 73 8 M10 PTH-B1 33 113 30 8 85 11 M10 2 PTH-A2
33 30 85 8 M10 PTHD-A2 45 60 85 8 M10 PTH-B2 45 125 30 8 97 11 M10 3 PTH-A3
60 30 100 8 M10 PTHD-A3 60 60 100 8 M10 PTH-B3 60 140 30 8 112 11 M10 4 PTH-A4
90 45 140 10 M12
PTHD-A4 90 90 140 10 M12 PTH-B4
90 190 45 10 160 14 M125 PTH-A5
122 60 180 10 M16
PTHD-A5 122 120 180 10 M15 PTH-B5 122 240 60 10 205 18 M16 6 PTH-A6
168 80 255 15 M20
PTHD-A6 168 160 225 15 M20 PTH-B6 168 310 80 15 270 22 M20 7 PTH-A7
205 90 270 15 M24
PTHD-A7 205 180 270 15 M24 PTH-B7 205 370 90 15 320 26 M24 8 PTH-A8
265 120 340 25 M30 PTHD-A8 265 240 340 25 M30 PTH-B8 265 450 120 25 390 33 M30
Heavy Tube Clamp DIN3015
PEHEL Hydraulic Model: Heavy Tube Clamp PTH-A1-PTHD-A1-PTH-B1
QTY:
- heavy tube clamp; DIN3015 standard, from small to big size, 2 welding plate model for choice
Material:
‑Clamp insert: PP / PA / Aluminum
‑Metal hardware: Carbon steel(zinc‑plated), Stainless steel 304/316
Brand: Pehel, OEM
Color: Green / Black(plastic insert), Silver zinc plating(metal parts)
Connector Type: Heavy‑duty tube fixing clamp
Standard: DIN3015‑2 (Heavy Series)
About the item:
- 1.DIN3015‑2 heavy tube clamp covers full OD sizes from small to large for hydraulic piping systems
- 2.Optional PP, PA, aluminum clamp insert with zinc‑plated or stainless steel hardware for DIN3015 tube clamp
- 3.Heavy‑duty modular structure of DIN3015‑2 tube clamp realizes stable fixing and vibration damping performance
- 4.Strictly manufactured to DIN3015‑2 heavy series standard for high interchangeability with global fittings
- 5.Support Pehel standard and OEM service, customizable heavy tube clamp for your industrial mounting project
