PART NO. THREAD DIMENSIONS E F A B S1 P1T9-04-02 R1/4"-19 R1/8"-28 25.5 23.5 14 -04 R1/4"-19 R1/4"-19 25.5 25.5 14 -06-04 R3/8"-19 R1/4"-19 28.5 26.5 16 -06 R3/8"-19 R3/8"-19 28.5 28.5 16 -08-04 R1/2"-14 R1/4"-19 36 30.5 22 -08-06 R1/2"-14 R3/8"-19 36 32.5 22 -08 R1/2"-14 R1/2"-14 36 36 22 -12-08 R3/4"-14 R1/2"-14 43.5 39.5 27 -12 R3/4"-14 R3/4"-14 43.5 43.5 27 -16-12 R 1"-11 R3/4"-14 50 47.5 33 -16 R 1"-11 R 1"-11 50 50 33 -20-16 R1.1/4"-11 R 1"-11 59 56.5 41 -20 R1.1/4"-11 R1.1/4"-11 59 59 41 -24 R1.1/2"-11 R1.1/2"-11 62.5 62.5 48 -32 R2" -11 R2" -11 75 68 63
Pehel/Adaptor zinc plating BSPT Male 90 Degreepla
PEHEL Hydraulic Model: P1T9-SP-2003
QTY:
Material:carbon steel, stainless steel
Brand:Pehel,OEM
Color: Silver,zinc-nickle alloy electroplating
Connector Type:adaptor,elbow
Thread type:male,British
About the item:
1. "BSPT Thread 90-Degree Elbow for Tight Spaces"，Designed for hydraulic hose rerouting in confined areas, this right-angle fitting eliminates 2 potential leak points compared to bent tubes.
2. "Seal without Leakage – BSPT Male Tapered Thread"，The 55-degree BSPT cone thread creates a metal-to-metal seal under high pressure. No washer needed. Ideal for high-pressure hydraulic systems up to 315 bar.
3. "Stainless Steel 304 / 316 Corrosion Resistant"，Choose 304 or 316 stainless steel for marine environments or corrosive fluids. Carbon steel zinc-plated option also available.
4. "Heavy Duty High Pressure – No Burst, No Leak"，Engineered for construction machinery and industrial hydraulics. Hard sealing structure resists vibration and pressure spikes. Passed ISO test.
5. "BSPT to Metric / BSPP Adapter – Easy Connect"，Converts BSPT male to metric tube or BSPP female. No welding required. Perfect adaptor for retrofitting imported hydraulic systems.
6. "In Stock – Quick Repair & Replacement"Common sizes (1/4”, 3/8”, 1/2”) available for same-day shipping. Direct replacement for Eaton, Parker, or other brands. Ideal for emergency hydraulic repair.
