PART NO. THREAD DIMENSIONS E F A B L S1 S2 7TJ-04S R1/4"X19 7/16"X20 21.5 9 29.5 19 17 7TJ-04-05S Rc1/4"X19 1/2"X20 21.5 9.5 30 19 17 7TJ-06S Rc3/8"X19 9/16"X18 24 10.5 32.5 22 19 7TJ-08S Rc1/2"X14 3/4"X16 29 11 39.5 27 24 7TJ-08-10S Rc1/2"X14 7/8"X14 29 13 40 27 27 7TJ-12S Rc3/4"X14 1.1/16"X12 30.5 15 43 36 32 7TJ-16S Rc1"X11 1.5/16"X12 35 16 47.5 41 41
PEHEL/BSPT FEMALE/JIC FEMALE 74 SEAT
PEHEL Hydraulic Model: P7TJ-S
QTY:
BSPT FEMALE/JIC FEMALE 74 SEAT
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type 1: BSPT FEMALE
Thread Type 2: JIC FEMALE 74 SEAT
About the item:
1. Model P7TJ‑S hydraulic adapter combines BSPT female tapered thread and JIC female 74° cone seat connection ends.
2. 74‑degree cone metal‑to‑metal sealing provides stable leak‑proof performance for high‑pressure hydraulic circuits.
3. Rich size range covers multiple Rc‑BSPT and UNF‑JIC thread specifications for cross‑standard pipeline conversion.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, featuring good interchangeability and corrosion resistance.
5. Complies with SAE J514 standard, widely used for industrial and mobile machinery hydraulic system transitions.
