THREAD DIMENSIONS PART NO. E F A B L S1 S2 6B-02 G1/8"X28 G1/8"X28 10 33 49 14 14 6B-04 G1/4"X19 G1/4"X19 12 35 53 19 19 6B-04-06 G1/4"X19 G3/8"X19 12 35 55 22 22 6B-06 G3/8"X19 G3/8"X19 13.5 35 56.5 22 22 6B-06-08 G3/8"X19 G1/2"X14 13.5 39 62.5 27 27 6B-08 G1/2"X14 G1/2"X14 16 39 65 27 27 6B-08-06 G1/2"X14 G3/8"X19 16 35 61 27 22 6B-08-16 G1/2"X14 G1"X11 16 50 79 41 41 6B-10 G5/8"X14 G5/8"X14 17.5 40 67.5 30 30 6B-12 G3/4"X14 G3/4"X14 18.5 42 71.5 32 32 6B-12-08 G3/4"X14 G1/2"X14 18.5 39 68.5 32 27 6B-12-16 G3/4"X14 G1"X11 18.5 50 81.5 41 41 6B-16 G1"X11 G1"X11 20.5 50 84 41 41 6B-20 G1.1/4"X11 G1.1/4"X11 20.5 52 89.5 50 50 6B-24 G1.1/2"X11 G1.1/2"X11 23 55 93 55 55 6B-32 G2"X11 G2"X11 25.5 55 97.5 70 70
PEHEL/BSP MALE 60 ° SEAT BULKHEAD
PEHEL Hydraulic Model: P6B/P6B-LN
QTY:
BSP MALE 60 ° SEAT BULKHEAD
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: BULKHEAD ADAPTER
Thread Type: BSP 60 CONE MALE
ABOUT THE ITEM:
1. BSP Male 60° Seat Bulkhead — through-wall adapter with BSP male thread for panel or tank mounting.
2. 60° cone seat ensures a reliable, leak-tight metal-to-metal seal under pressure.
3. Allows hydraulic lines to pass through panels and bulkheads while keeping installation compact.
4. Precision-machined carbon steel construction delivers high strength and long service life.
5. Widely used in hydraulic, pneumatic, oil and gas systems for secure, space-saving connections.
