THREAD DIMENSIONS PART NO. E F A B S1 S2 2B9-02 G1/8"X28 G1/8"X28 19.8 6 11 14 2B9-04 G1/4"X19 G1/4"X19 24.5 5 14 19 2B9-04-06 G1/4"X19 G3/8"X19 25 6.5 14 22 2B9-06 G3/8"X19 G3/8"X19 27.5 6.5 16 22 2B9-06-04 G3/8"X19 G1/4"X19 27.5 5 16 19 2B9-08 G1/2"X14 G1/2"X14 34.5 7.8 22 27 2B9-08-06 G1/2"X14 G3/8"X19 34.5 6.5 22 22 2B9-10 G5/8"X14 G5/8"X14 35 9 22 30 2B9-10-08 G5/8"X14 G1/2"X14 35 7.8 22 27 2B9-12 G3/4"X14 G3/4"X14 40 10.5 27 32 2B9-16 G1"X11 G1"X11 46 11 33 41 2B9-20 G1.1/4"X11 G1.1/4"X11 50.5 11.5 41 50 2B9-24 G1.1/2"X11 G1.1/2"X11 57.5 12.5 48 55 2B9-32 G2"X11 G2"X11 70 17 63 70
Pehel | 90 Degree Elbow BSP Male 60° Seat Hydraulic Hose Fitting
PEHEL Hydraulic Model: P2B9
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
- 1.Premium carbon steel & stainless steel 90 degree BSP male elbow with silver zinc plating for anti-corrosion performance
- 2.Standard BSP male thread with precise 60° seat cone ensures tight leak-free hydraulic connection
- 3.Compact 90° elbow connector optimizes hydraulic pipeline layout for narrow equipment installation
- 4.Factory direct Pehel hydraulic fitting supports OEM customization for all hydraulic hose assemblies
- 5.High pressure resistant BSP 60° seat adapter stable for construction machinery hydraulic systems
