PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH C D L Per hundred weight Weight per case 87613-12-12 3/4" 20 12 41.3 32 8.76 28.4 60 87613-16-12 1" 20 12 47.6 38 9.53 35.5 45 87613-16-16 1" 25 16 47.6 38 9.53 42.4 40 87613-20-16 1.1/4" 25 16 54 44 10.29 54.6 35 87613-20-20 1.1/4" 32 20 54 44 10.29 68 30 87613-24-20 1.1/2" 32 20 63.5 51 12.57 88.7 25 87613-24-24 1.1/2" 40 24 63.5 51 12.57 108.6 15 87613-32-24 2" 40 24 79.4 67 12.57 142.2 10 87613-32-32 2" 50 32 79.4 67 12.57 216.9 6/8
PEHEL/ SAE Female 6000 PSI
PEHEL Hydraulic Model: P87613
QTY:
6000psi hydraulic flanges Interlock type
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: elbow
Thread Type: Swage Crimp End
About the item:
1. Conforms to SAE J518 Code 62 high-pressure standard, rated for a maximum working pressure of 6000 PSI (42MPa). Equipped with flat-face O-ring sealing structure to deliver stable leak-proof performance under pressure pulsation, shock load and long-term vibration.
2. Made of high-strength 45# carbon steel with precision CNC machining and uniform zinc-plated anti-rust surface treatment, featuring balanced hardness and impact resistance, effectively extending service life in harsh industrial hydraulic environments.
3. Adopts interlock crimp tail design, requiring internal & external skiving of matched hydraulic hoses during assembly. The double locking structure firmly combines the nipple, ferrule and hose reinforcement layer to avoid hose pull-out under extreme high pressure.
4. Complete full-size specifications covering flange thread from 3/4" to 2", compatible with hose bore DN20-DN50 (Dash 12 to Dash 32). Standardized dimensional parameters enable full interchangeability with mainstream global hydraulic flange clamps and hose assemblies.
5. Optimized for heavy-duty high-pressure hydraulic circuits, widely applied in excavators, injection molding machines, metallurgical equipment, mining machinery and marine hydraulic systems. The four-bolt flange connection needs lower assembly torque than large threaded joints, convenient for installation in narrow spaces.
