PART NO.
THREAD DIMENSIONS E F A B L S P1BE-04-14 G1/4"X19 M14X1.5 12 11 29 19 P1BE-06-16 G3/8"X19 M16X1.5 13.5 11 32.5 22 P1BE-06-16 G3/8"X19 M18X1.5 13.5 11 32.5 22 P1BE-08-22 G1/2"X14 M22X1.5 16 12 38 27 P1BE-10-27 G5/8"X14 M27X1.5 17.5 13 40.5 30 P1BE-12-30 G3/4"X14 M30X1.5 18.5 14 43.5 32 P1BE-16-36 G1"X11 M36X2 20.5 16 49.5 41 P1BE-16-39 G1"X11 M39X2 20.5 18 51.5 41 P1BE-20-39 G1.1/4"X11 M39X2 20.5 18 53.5 50 P1BE-20-45 G1.1/4"X11 M45X2 20.5 20 55.5 50
PEHEL/BSP MALE 60° SEAT OR BONDED SEAL/METRIC MALE O-RING FLAT SEAL
PEHEL Hydraulic Model: P1BE
QTY:
BSP MALE 60° SEAT OR BONDED SEAL/METRIC MALE O-RING FLAT SEAL
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: ADAPTER
Thread Type 1: BSP MALE 60° SEAT
Thread Type 2: METRIC MALE O-RING FLAT SEAL
About the item:
1. 1BE is straight transition adapter with BSP male (60° seat or bonded‑seal) and metric male O‑ring flat‑seal ends.
2. Dual‑option BSP side supports 60‑degree cone seat or bonded‑gasket sealing; metric side relies on O‑ring flat face seal for leak‑free connection.
3. Wide thread coverage includes G1/4"‑G1‑1/4" BSP and M14×1.5‑M45×2 metric threads for cross‑standard conversion needs.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, ensuring good interchangeability and corrosion resistance.
5. Compact straight‑through design widely used for connecting BSP and metric ports on industrial and mobile hydraulic machinery.
