PART NO. FLANGE SIZE HOSE BORE DIMENSIONS DN DASH A B F 87311-08-08PKAST 1/2" 12 08 88 54 30.2 87311-10-10PKAST 5/8" 16 10 96 57.2 34.2 87311-12-12PKAST 3/4" 20 12 90 50.9 38.1 87311-16-16PKAST 1" 25 16 108 63.2 44.4 87311-20-20PKAST 1.1/4" 32 20 119 72 50.8
Pehel/87311PK/High Pressure 3000PSI FL SAE Flange One Piece Fitting
PEHEL Hydraulic Model: P87311-PK
QTY:
SAE 3000 PSI Flange Code 61 Flnage Hydraulic Flange Fitting
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Straight
Thread Type: SAE FL Flange
About the item:
1.Rated for 3000 PSI (High Pressure) – Engineered to withstand extreme hydraulic pressures, ensuring reliable performance in demanding industrial applications.
2.SAE Flange Standard Compliance – Fully conforms to SAE J518 code 61/62 specifications, guaranteeing seamless compatibility with standard hydraulic systems.
3.Easy Installation & Time Savings – Simple bolt-on design allows quick and secure assembly, reducing installation time and labor costs.
- Features
