PART NO.
THREAD DIMENSIONS E F A B L S1 S2 P7TB-02-04S R1/8"X28 G1/4"X19 15.5 5.5 26.5 17 19 P7TB-04S R1/4"X19 G1/4"X19 20 5.5 31 19 19 P7TB-04-06S R1/4"X19 G3/8"X19 20 6.3 32.2 19 22 P7TB-06S R3/8"X19 G3/8"X19 23 6.3 35.2 22 22 P7TB-06-04S R3/8"X19 G1/4"X19 23 5.5 34 22 19 P7TB-06-08S R3/8"X19 G1/2"X14 23 7.5 37 22 27 P7TB-08-06S R1/2"X14 G3/8"X19 28 6.3 40.2 27 22 P7TB-08S R1/2"X14 G1/2"X14 28 7.5 42 27 27 P7TB-08-12S R1/2"X14 G3/4"X14 28 10.9 43.1 27 32 P7TB-12-08S R3/4"X14 G1/2"X14 30 7.5 44 36 27 P7TB-12S R3/4"X14 G3/4"X14 30 10.9 45.1 36 32 P7TB-12-16S R3/4"X14 G1"X11 30 11.7 46.3 36 41 P7TB-16-12S R1"X11 G3/4"X14 35 10.9 50.1 41 32 P7TB-16S R1"X11 G1"X11 35 11.7 51.3 41 41
Pehel | BSPT Female to BSP Female Hydraulic Joint
PEHEL Hydraulic Model: 7TB-S
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type: straight transit adapter
Thread Type:
About the item:
- 1.BSPT female to BSP female hydraulic joint with precisely machined BSP thread for tight leak-free hydraulic connections
- 2.Available in carbon steel and stainless steel to fit different hydraulic system working environments
- 3.Silver zinc plating surface treatment improves corrosion resistance for long service life
- 4.High pressure resistant hydraulic fitting, stable performance under continuous hydraulic vibration
- 5.Pehel brand and OEM service supported, custom sizes of BSP hydraulic connectors are acceptable
- 6.Standard BSP hydraulic adapter widely used for industrial machinery hydraulic pipeline systems
