PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C H S2 20641-14-04T M14X1.5 6 04 42.5 5.5 20.5 17 20641-16-05T M16X1.5 8 05 45 5.5 22 19 20641-18-06T M18X1.5 10 06 48 5.5 23 22 20641-22-08T M22X1.5 12 08 61.5 6 27 27 20641-27-10T M27X1.5 16 10 74.5 6 29.5 32 20641-30-12T M30X1.5 20 12 82 6 33.5 36 20641-36-14T M36X2 22 14 81.9 6.5 31.6 41 20641-39-16T M39X2 25 16 88.5 6.5 34.3 46 20641-45-20T M45X2 32 20 99.1 8.5 38.4 50 20641-54-24T M52X2 40 24 113.4 10 42.7 60 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 20642-XX-XX。
PEHEL | 45° Metric Female 60° Cone Hose Fitting, Hydraulic Crimp Fitting
PEHEL Hydraulic Model: P20641-T
QTY:
45 degree metric female 60 degree cone 20641 China supplier
- 20641: 45 degree elbow, 1 wire tail.
Material: Carbon steel
Brand: PEHEL, OEM
Angle: 45° Elbow
Connector Type: Crimp Fitting
Thread Type: Metric Female
Sealing: 60° Cone Seat
About the item:
1.45° metric female 60° cone hose fitting, engineered as a crimp-style hydraulic adapter for metric hydraulic hose assemblies in fluid power systems.
2.Female metric threads with 60° cone sealing face provide reliable metal-to-metal seal against standard metric male cone ends, ensuring leak-proof performance under high pressure.
3.45° elbow configuration allows efficient redirection of fluid flow in tight spaces, optimizing hydraulic circuit layout and saving installation space.
4.Designed for crimping onto hydraulic hoses with standard metric hose fittings, ensuring a robust and durable hold that withstands heavy-duty industrial applications.
5.Manufactured from high-strength carbon steel with anti-rust surface treatment, offering excellent durability and corrosion resistance in demanding hydraulic environments.
