PART NO. THREAD O-RING DIMENSIONS E F G E F G A B C S1 S2 AFFG-04OG 9/16"X18 9/16"X18 G1/4"X19 O011 O011 O111 23 23 31.3 14 19 AFFG-04-04-06OG 9/16"X18 9/16"X18 G3/8"X19 O011 O011 O113 23.5 23.5 35.5 16 22 AFFG-06-06-04OG 11/16"X16 11/16"X16 G1/4"X19 O012 O012 O111 27 27 33.5 19 19 AFFG-06OG 11/16"X16 11/16"X16 G3/8"X19 O012 O012 O113 27.5 27.5 36.8 19 22 AFFG-08-08-06OG 13/16"X16 13/16"X16 G3/8"X19 O014 O014 O113 31 31 39.5 22 22 AFFG-08OG 13/16"X16 13/16"X16 G1/2"X14 O014 O014 O115 31 31 43.2 22 27 AFFG-10-10-12OG 1"X14 1"X14 G3/4"X14 O016 O016 O119 36.5 36.5 49.3 27 32 AFFG-12OG 1.3/16"X12 1.3/16"X12 G3/4"X14 O018 O018 O119 41.5 41.5 53.5 30 32 AFFG-16OG 1.7/16"X12 1.7/16"X12 G1"X11 O021 O021 O217 44.5 44.5 56 36 41
Pehel/AFFG-OG/Male ORFS Flat O-ring-Male ORFS FLat O-ring-BSP O-ring Seal Run Tee Connector
PEHEL Hydraulic Model: PAFFG-OG
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Tee
Thread Type: ORFS/ORFS/BSP
About the item:
1.Hardened carbon steel body with anti-rust coating, resists vibration and harsh industrial environments for long service life.
2.Fully compliant with ISO, SAE and DIN standards, quick to install without extra sealant.
3.Wide size range from 1/4" to 2", compatible with most hydraulic hoses on the market.
4.Premium hydraulic tee fitting, perfect for construction machinery, agricultural equipment and automation lines.
