PART NO. THREAD O-RING DIMENSIONS E F E A B S1 1FN4-04-02 9/16"X18 Z1/8"X27 O011 18.3 18 14 1FN4-04 9/16"X18 Z1/4"X18 O011 18.3 21 14 1FN4-04-06 9/16"X18 Z3/8"X18 O011 19.5 25 19 1FN4-06-04 11/16"X16 Z1/4"X18 O012 20.5 22 19 1FN4-06 11/16"X16 Z3/8"X18 O012 20.5 25 19 1FN4-06-08 11/16"X16 Z1/2"X14 O012 22 29.5 22 1FN4-08-06 13/16"X16 Z3/8"X18 O014 24 26 22 1FN4-08 13/16"X16 Z1/2"X14 O014 24 29.5 22 1FN4-10-08 1"X14 Z1/2"X14 O016 28 31 27 1FN4-12 1.3/16"X12 Z3/4"X14 O018 30.7 35.5 30 1FN4-16 1.7/16"X12 Z1"X11.5 O021 33 40 36 1FN4-20 1.11/16"X12 Z1.1/4"X11.5 O025 35.5 42.5 41 1FN4-24 2"X12 Z1.1/2"X11.5 O029 39 46.5 50
Pehel | 45° Elbow ORFS Male O-Ring to NPT Male hydraulic joint
PEHEL Hydraulic Model: P1FN4
QTY:
- Brand: Pehel, OEM Available
- Material: Carbon Steel, Stainless Steel
- Type: 45° Elbow Hydraulic Fitting
- Connection: ORFS Male O-Ring, NPT Male
- Application: High pressure hydraulic pipeline connection
- Feature: Leak-proof sealing, precision machining
- Customization: Accept OEM custom orders
About the item:
- This 45° elbow ORFS male O-ring to NPT male fitting delivers reliable high-pressure hydraulic connection.
- ORFS male O-ring design provides excellent sealing performance to prevent fluid leakage.
- NPT male thread ensures tight thread connection for industrial hydraulic pipeline assembly.
- Precision machined 45 degree elbow optimizes pipe routing and reduces installation stress.
- Available in carbon steel and stainless steel with multiple anti-corrosion surface treatments.
- Pehel supplies standard hydraulic fittings and accepts OEM custom orders for hydraulic systems.
