One wire Ferrule Description: the material is Q235 steel. P00100, P00110 are most ordered hydraulic ferrule.
PART NO. HOSE BORE DIMENSIONS DN DASH D L P00100-03 4 3 17.5 27 P00100-04 6 4 20.6 30 P00100-05 8 5 21.5 31 P00100-06 10 6 24 32 P00100-08 12 8 28.5 34 P00100-10 16 10 32 37 P00100-12 20 12 26 43 P00100-16 25 16 43 50 P00100-20 32 20 50.5 59 P00100-24 40 24 57 74 P00100-32 50 32 70.6 78
Skive Ferrule for SAE 100R1AT | EN 853 1SN Hose
PEHEL Hydraulic Model: P00100
QTY:
Hydraulic factory direct Carbon Steel 2023 sae 100R1 AT/EN853 1SN hydraulic hose carbon steel/ stainless steel ferrule joint
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: Ferrule
Thread Type: Non-threaded Ferrule
Surface Treatment: CR3+ White Zinc Plated
About the item:
1.Heavy-Duty Carbon Steel: Manufactured from solid carbon steel, the ferrule provides exceptional burst strength for demanding hydraulic applications up to 4000 PSI.
2.Anti-Corrosion Coating: Finished with silver color zinc plating, the sleeve resists rust and extends service life in humid or outdoor environments.
3.Standard Compliance: Fully compatible with EN 853 1SN specifications, guaranteeing interchangeability with international hydraulic hose brands and crimping machines.
4.Reliable OEM Supply: Available under the trusted Pehel brand or as custom OEM hydraulic parts to match your specific assembly line requirements.
Leak-Proof Assembly: It ensures uniform compression, creating a permanent, zero-leak connection between hose and fitting.
