THREAD DIMENSIONS PART NO. E F G A B C S1 JN-02 Z1/8"X27 Z1/8"X27 Z1/8"X27 17.8 24.5 17.8 16 JN-04 Z1/4"X18 Z1/4"X18 Z1/4"X18 22.4 28 22.4 19 JN-06 Z3/8"X18 Z3/8"X18 Z3/8"X18 25 33.5 25 24 JN-08 Z1/2"X14 Z1/2"X14 Z1/2"X14 31.2 41.2 31.2 30 JN-12 Z3/4"X14 Z3/4"X14 Z3/4"X14 34.5 45.2 34.5 33 JN-16 Z1"X11.5 Z1"X11.5 Z1"X11.5 41.1 54.5 41.1 41
JN Series Equal NPT Female Tee Hydraulic Pipe Fitting | 3 Way NPT Taper Thread Adapte NPT Female Tee Hydraulic Pipe Fitting
PEHEL Hydraulic Model: PJN
QTY:
Material: Carbon, stainless
Brand: Pehel, OEM
Color: Zinc galvanized
Connector Type: Equal npt tee
Thread Type: NPT
- About the item:
- 1.Equal female NPT three-way tee fitting, same NPT thread on three ports for pipeline split connection.
- 2.Precision CNC machining NPT taper thread, tight thread fit, good self-sealing performance with PTFE tape.
- 3.Carbon steel galvanized surface, anti-rust & anti-corrosion, stable under medium-high hydraulic pressure.
- 4.Standard hex body for easy spanner installation, widely used in hydraulic & pneumatic piping, machinery equipment.
- 5.Full sizes in stock from 1/8'' to 1'' NPT, support OEM custom service.
