PART NO.
THREAD
TUBE O.D.
DIMENSIONS
E
A
D
S2
2WE-06-12
M12X1.25
6
8
6
14
2WE-08-14
M14X1.5
8
8.5
8
17
2WE-10-16
M16X1.5
10
8.5
10
19
2WE-12-18
M18X1.5
12
8.5
12
22
2WE-14-22
M22X1.5
14
10
14
27
2WE-18-27
M27X1.5
18
10
18
32
2WE-22-30
M30X1.5
22
11
22
36
2WE-28-36
M36X2
28
13
28
41
2WE-30-39
M39X2
30
13
30
46
2WE-34-42
M42X2
34
15
34
50
2WE-38-45
M45X2
38
15
38
55
2WE-42-52
M52×2
42
17
42
60
2WE-50-60
M60X2
50
20
50
70
2WE-52-64
M64X2
52
23
52
75
Butt-weld Tube / Metric Female O-ring
PEHEL Hydraulic Model: P2WE
QTY:
