PART NO.
THREAD DIMENSIONS E F D1 D2 L1 L2 S1 P6D9-14 M14X1.5 M14X1.5 6 6 40 36.5 14 P6D9-16 M16X1.5 M16X1.5 8 8 42 36.5 16 P6D9-18 M18X1.5 M18X1.5 10 10 45 37 19 P6D9-20 M20X1.5 M20X1.5 12 12 50 38 22 P6D9-22 M22X1.5 M22X1.5 14 14 53 38.5 22 P6D9-24 M24X1.5 M24X1.5 16 16 57 40 24 P6D9-30 M30X2 M30X2 20 20 67 44 30 P6D9-36 M36X2 M36X2 25 25 76 47 36 P6D9-42 M42X2 M42X2 30 30 87 51 41 P6D9-52 M52X2 M52X2 38 38 100 53 55
PEHEL/90° Elbow Bulkhead Fittings
PEHEL Hydraulic Model: P6D9
QTY:
90° Elbow Bulkhead Fittings
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: elbow
Thread Type: Metric male
About the item:
1. Model P6D9 is 90‑degree metric bulkhead elbow fitting for tube connection through equipment panels.
2. 24‑degree cone bite‑type sealing delivers reliable leak‑proof performance for high‑pressure hydraulic circuits.
3. Full size range covers M14×1.5 to M52×2 metric threads for various tube outer diameter specifications.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, compliant with DIN2353 standard for good interchangeability.
5. Panel‑mount elbow layout optimizes piping routing, widely used for industrial and mobile hydraulic equipment assembly.
