PART NO.
THREAD DIMENSIONS E F D1 D2 L1 L2 S1 P6C9-12 M12X1.5 M12X1.5 6 6 33 34 11 P6C9-14 M14X1.5 M14X1.5 8 8 38 34 14 P6C9-16 M16X1.5 M16X1.5 10 10 40 35 16 P6C9-18 M18X1.5 M18X1.5 12 12 44 36 19 P6C9-22 M22X1.5 M22X1.5 15 15 51 38 22 P6C9-26 M26X1.5 M26X1.5 18 18 55 40 27 P6C9-30 M30X2 M30X2 22 22 65 42 30 P6C9-36 M36X2 M36X2 28 28 72 43 36 P6C9-45 M45X2 M45X2 35 35 84 47 48 P6C9-52 M52X2 M52X2 42 42 94 47 55
PEHEL | 90 Elbow Metric Bulkhead Adapter| Precision CNC Machining
PEHEL Hydraulic Model: P6C9
QTY:
Material: Carbon steel, Stainless Steel, Aluminium, Brass
Brand: Pehel, OEM
Color: Silver
Connector Type: Straight
Thread Type: Hydraulic Hose Adapter
1. High tensile strength, withstand heavy-Load hydraulic pressure.
2. Strict dimension tolerance, consistent crimping result batch to batch.
3. Designed for hydraulic hose crimp-on assembly.
