Home / Hydraulic Adapter / Metric Standard / Metric FEM/MALE/FEM 24º L.T.

Metric FEM/MALE/FEM 24º L.T.

PEHEL Hydraulic Model: PEC

QTY:

  • You May Also Like

  • PART NO.

    THREAD TUBE O.D. DIMENSIONS
    EFG D1D2D3 AC B S1 S2 S3
    PEC-14 M14X1.5 8 2 25.3 14 19 19
    -16 M16X1.5 10 2 27.2 16 22 22
    -18 M18X1.5 12 2.5 28.5 19 24 24
    -22 M22X1.5 15 2.5 30.5 22 27 27
    -26 M26X1.5 18 2.5 35.5 27 32 32
    -30 M30X2 22 4 41 30 36 36
    -36 M36X2 28 4 44.7 36 41 41
    -45 M45X2 35 5 52.5 48 55 55
    -52 M52X2 42 5.5 58.5 55 60 60
