PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A B S1 18611-14-04 M14X1.5 6 04 29.5 17 17 18611-14-06 M14X1.5 10 06 29.5 17 17 18611-16-04 M16X1.5 6 04 30.5 18 17 18611-16-06 M16X1.5 10 06 30.5 18 17 18611-18-06 M18X1.5 10 06 30.5 18 19 18611-20-08 M20X1.5 12 08 35 20 22 18611-22-08 M22X1.5 12 08 35 20 24 18611-24-10 M24X1.5 16 10 38.5 21.5 27 18611-30-12 M30X1.5 20 12 43.5 26 32 18611-33-16 M33X1.5 25 16 50.5 30 36 18611-36-20 M36X1.5 32 20 55 33 41 18611-42-24 M42X1.5 40 24 59 36 46 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 18612-XX-XX。
Pehel | BSP Female 60° Cone Hydraulic Pipe Connector - BSPP Threaded Fitting, Zinc Plated
PEHEL Hydraulic Model: P18611
QTY:
18611 Japanese Metric Male Straight Fittings, 60° Cone Seat
Fetures:
JIS is equivalent to BSP thread (both tapered and parallel). But JIS has a 30° flared seat in the female variant and cone in the male variant (similar to the seat/cone system in JIC fittings)
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.Precision-machined BSP female 60° cone hydraulic pipe connector in zinc plated carbon steel for excellent corrosion resistance and long service life.
- 2.The 60 degree cone seat pairs with standard cone male ends for leak-tight, metal-to-metal sealing in high-pressure hydraulic systems.
- 3.Precision BSPP female threads ensure accurate, repeatable assembly and interchangeability with standard BSP fittings and hoses.
- 4.Available in carbon steel or stainless steel to OEM specifications, matching your original hydraulic pipe connector dimensions for direct replacement.
- 5.Silver zinc plating on each BSP female connector resists rust, oil and abrasion, ideal for construction, agricultural and industrial equipment.
