light tube clamp: Structure: assembly including cover plate, rail nut, clamp body,hexagon bolts
Clamp size Cover plate Slot head
screw
(GB65-85)
d×1Socket head
screw
(GB70-85)
d×1Hexagon head
bolt
(GB5782-86)
d×1Stacking bolt Locking plate Order code Size Order code Size Order code b d a b 0 PTL-G0 - - M6×20 M6×20 M6×30 PTL-H0 20 34
PTL-L 1 PTL-G1 34 20 M6×20 M6×20 M6×30 PTL-H1 20 34 2 PTL-G2 40 26 M6×25 M6×25 M6×35 PTL-H2 25 39 3 PTLG3 48 33 M6×30 M6×30 M6×40 PTL-H3 30 44 4 PTL-G4 57 40 M6×35 M6×35 M6×45 PTL-H4 35 49 5 PTL-G5 70 52 M6×50 M6×50 M6×60 PTL-H5 50 64 6 PTL-G6 86 66 M6×60 M6×60 M6×70 PTL-H6 60 74
Hydraulic Light Tube Clamp DIN 3015 Carbon Steel Zinc Plated
PEHEL Hydraulic Model: PTL-G, PTL-H
QTY:
- light pipe clampOuter-hexagon socket screw +clamp body +cover plate +welded base plateBody color: GreenBody material Type: Plastic or Nylon
About the item:
1.DIN 3015 Standard Compliance: Manufactured to strict DIN 3015 standards, ensuring perfect interchangeability and reliable performance for your hydraulic and pneumatic systems.
2.Dual Material Options: Available in high-grade carbon steel for superior strength and stainless steel for excellent corrosion resistance in harsh environments.
3. Versatile Application: This light tube clamp is engineered to securely hold pipes, tubes, and hoses, minimizing vibration and noise in industrial machinery.
4. OEM & Custom Branding: Support for Pehel and OEM branding, allowing you to customize the product to meet specific market demands and build brand recognition.
5. Easy & Secure Installation: Designed for quick assembly and disassembly, the clamp ensures a tight, leak-proof grip while simplifying maintenance in complex hydraulic setups.
