PART NO. THREAD DIMENSIONS E F G A B C S1 AJJN-04 7/16"X20 7/16"X20 Z1/4"X18 26.6 26.6 25.5 14 AJJN-04-04-02 7/16"X20 7/16"X20 Z1/8"X27 24.5 24.5 21 11 AJJN-05-05-02 1/2"X20 1/2"X20 Z1/8"X27 26.6 26.6 23.5 14 AJJN-06 9/16"X18 9/16"X18 Z3/8"X18 30 30 31 19 AJJN-06-04-06 9/16"X18 7/16"X20 Z3/8"X18 26.9 25.5 26.9 14 AJJN-06-06-04 9/16"X18 9/16"X18 Z1/4"X18 26.9 26.9 25.5 14 AJJN-08 3/4"X16 3/4"X16 Z1/2"X14 34.8 34.8 36.7 22 AJJN-08-08-06 3/4"X16 3/4"X16 Z3/8"X18 32 32 31 19 AJJN-10-10-08 7/8"X14 7/8"X14 Z1/2"X14 37.8 37.8 36.7 22 AJJN-10-10-12 7/8"X14 7/8"X14 Z3/4"X14 41 41 44 27 AJJN-12 1.1/16"X12 1.1/16"X12 Z3/4"X14 44.2 44.2 44 27 AJJN-16 1.5/16"X12 1.5/16"X12 Z1"X11.5 49 49 50 33 AJJN-20 1.5/8"X12 1.5/8"X12 Z1.1/4"X11.5 55.5 55.5 54.5 41 AJJN-24 1.7/8"X12 1.7/8"X12 Z1.1/2"X11.5 62.5 62.5 63 48
PEHEL / AJJN / Hydraulic Adapter JIC Male Run Tee Adaptor Long Life Service
PEHEL Hydraulic Model: PAJJN
QTY:
Hydraulic Adaptor JIC 74° Cone Male Run Tee Carbon Steel Threaded Fitting
Material: Carbon steel
Surface Treatment: White Zinc Plating
Brand: PEHEL, OEM
Color: Silver
Connector Type: Straight
Thread: JIC
1. PEHE JIC 74° cone run tee adapter for leak-free hydraulic connections.
2. Carbon steel construction with zinc plating ensures superior durability and corrosion resistance.
3. Compliant design delivers reliable sealing under high pressure and extreme temperatures.
4. Compatible with multiple fluid types, including oil, water, and air.
5. JIC 74° cone prevents fluid escape in demanding industrial applications.
