PART NO. THREAD O-RING DIMENSIONS E F G F A B C S1 S2 AJGJ-04-02-04OG 7/16"X20 G1/8"X28 7/16"X20 O011 24.5 26.2 24.5 11 14 AJGJ-04OG 7/16"X20 G1/4"X19 7/16"X20 O111 26.6 31.8 26.6 14 19 AJGJ-05-02-05OG 1/2"X20 G1/8"X28 1/2"X20 O011 26.6 29 26.6 14 14 AJGJ-05-04-05OG 1/2"X20 G1/4"X19 1/2"X20 O111 26.6 31.8 26.6 14 19 AJGJ-06-04-06OG 9/16"X18 G1/4"X19 9/16"X18 O111 27 31 27 14 19 AJGJ-06OG 9/16"X18 G3/8"X19 9/16"X18 O113 28.5 35.8 28.5 16 22 AJGJ-08-06-08OG 3/4"X16 G3/8"X19 3/4"X16 O113 32 36.8 32 19 22 AJGJ-08OG 3/4"X16 G1/2"X14 3/4"X16 O115 35 43.2 35 22 27 AJGJ-10-08-10OG 7/8"X14 G1/2"X14 7/8"X14 O115 37.8 43.5 37.8 22 27 AJGJ-12OG 1.1/16"X12 G3/4"X14 1.1/16"X12 O119 44.2 51 44.2 27 32 AJGJ-16OG 1.5/16"X12 G1"X11 1.5/16"X12 O217 48.8 53 48.8 33 41
PEHEL | JIC MALE 74° CONE / BSP MALE O-RING BRANCH TEE | Direct Factory Supply
PEHEL Hydraulic Model: PAJGJ-OG
QTY:
Material: Carbon steel, Stainless Steel, Aluminium, Brass
Brand: Pehel, OEM
Color: Silver
Connector Type: Tee
Thread Type: Hydraulic Hose Adapter
1. Precision machined with strict tolerance control
2. Smooth inner bore, reduce jamming caused by impurities
3. Premium surface treatment for good rust resistance
4. Batch inspected, stable & controllable quality
5. Consistent quality for bulk orders
