THREAD O-RING DIMENSIONS PART NO. E F G G A B C S1 S2 AKKH-14-14-12OG M14X1.5 M14X1.5 M12X1.5 O09.3X2.4 25.5 25.5 33.5 14 17 AKKH-14OG M14X1.5 M14X1.5 M14X1.5 O11.3X2.4 27.5 27.5 34.5 14 19 AKKH-16-16-14OG M16X1.5 M16X1.5 M14X1.5 O11.3X2.4 28.5 28.5 35.5 16 19 AKKH-18-18-14OG M18X1.5 M18X1.5 M14X1.5 O11.3X2.4 30.8 30.8 37.5 19 19 AKKH-18-18-16OG M18X1.5 M18X1.5 M16X1.5 O13.3X2.4 30.8 30.8 39.5 19 22 AKKH-18-18-20OG M18X1.5 M18X1.5 M20X1.5 O17.3X2.4 30.8 30.8 44 19 27 AKKH-20-20-18OG M20X1.5 M20X1.5 M18X1.5 O15.3X2.4 33 33 42.5 19 24 AKKH-22-22-20OG M22X1.5 M22X1.5 M20X1.5 O17.3X2.4 35 35 45.5 22 27 AKKH-24-24-20OG M24X1.5 M24X1.5 M20X1.5 O17.3X2.4 40 40 47 24 27 AKKH-24-24-22OG M24X1.5 M24X1.5 M22X1.5 O19.3X2.4 40 40 47 24 27 AKKH-30-30-27OG M30X1.5 M30X1.5 M27X2 O23.5X3.0 48 48 57 30 32 AKKH-33OG M33X1.5 M33X1.5 M33X2 O29.5X3.O 54.5 54.5 59 33 41 AKKH-36-36-33OG M36X1.5 M36X1.5 M33X2 O29.5X3.0 57 57 60.5 36 41
PEHEL | JIS Metric Male 60°Cone Hydraulic Hose Adapter | OEM Service Supported
PEHEL Hydraulic Model: PAKKH-OG
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: Straight
Thread Type: JIS Metric
1. Ready Stock Fast Dispatch
2. Low MOQ Support OEM ODM
3. Strict Factory QC Inspection
4. Custom Size & Surface Treatment Available
