PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C S2 10611-14-04 M14X1.5 6 04 23.5 11 19 10611-16-05 M16X1.5 8 05 26.5 12 22 10611-18-06 M18X1.5 10 06 29 12 24 10611-22-08 M22X1.5 12 08 31.5 14 27 10611-26-10 M26X1.5 16 10 35 16 32 10611-26-10D M27X1.5 16 10 36 16 32 10611-27-1D M27X2 16 10 36 16 32 10611-30-12D M30X1.5 20 12 39.5 18 36 10611-30-12 M30X2 20 12 39.5 18 36 10611-33-16 M33X2 25 16 43.7 20 46 10611-45-20 M45X2 32 20 46 20 55 10611-52-24 M52X2 40 24 46 20 60 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 10612-XX-XX。
Pehel | Metric Male Double‑Use Hydraulic Fitting, 60°Cone Seat & Bonded Seal
PEHEL Hydraulic Model: P10611
QTY:
10611 Metric Male Double Use for 60° Cone Seat or Bonded Seal Instrumentation Tube Fitting
- Material: Carbon steel, stainless steel
- Brand: Pehel, OEM
- Color: Silver color zinc plating
- Connector Type: Metric Male Double‑Use
- Thread Type: Metric Thread
About the item:
- 1.Dual‑purpose metric male hydraulic fitting fits both 60° cone seat and bonded seal installation scenarios.
- 2.Premium carbon steel & stainless steel material delivers high pressure resistance for hydraulic piping systems.
- 3.Silver zinc‑plated surface effectively resists corrosion, extending service life of hydraulic pipe fitting.
- 4.Strictly machined metric thread ensures tight leak‑free connection for hydraulic fluid transmission.
- 5.Support Pehel brand and OEM custom service to meet diverse hydraulic adapter project requirements.
