THREAD O-RING DIMENSIONS PART NO. E,F G G A B C S1 S2 AKKG-14-14-04OG M14X1.5 G1/4"X19 O111 26.5 26.5 31.5 14 19 AKKG-14-14-06OG M14X1.5 G3/8"X19 O113 28.5 28.5 35.5 16 22 AKKG-16-16-06OG M16X1.5 G3/8"X19 O113 28 28 35.8 16 22 AKKG-18-18-06OG M18X1.5 G3/8"X19 O113 30.8 30.8 37 19 22 AKKG-22-22-08OG M22X1.5 G1/2"X14 O115 35.5 35.5 43 22 27 AKKG-24-24-08OG M24X1.5 G1/2"X14 O115 40 40 46 27 27 AKKG-24-24-12OG M24X1.5 G3/4"X14 O119 40 40 49.3 27 32 AKKG-30-30-12OG M30X1.5 G3/4"X14 O119 47.5 47.5 53 30 32 AKKG-33-33-16OG M33X1.5 G1"X11 O217 50 50 53 33 41
JIS Metric Male
PEHEL Hydraulic Model: PAKKG-OG
QTY:
