THREAD DIMENSIONS PART NO. E A L S1 4S-04 G1/4"X19 16 24 17 4S-06 G3/8"X19 18 24 19 4S-08 G1/2"X14 20 28 22 4S-12 G3/4"X14 22 32 30 4S-16 G1"X11 24 35 36
JIS Gas Male 60° Cone Plug
PEHEL Hydraulic Model: P4S
QTY:
PEHEL Hydraulic Model: P4S
QTY:
| THREAD | DIMENSIONS | ||||||||
| PART NO. | |||||||||
| E | A | L | S1 | ||||||
| 4S-04 | G1/4"X19 | 16 | 24 | 17 | |||||
| 4S-06 | G3/8"X19 | 18 | 24 | 19 | |||||
| 4S-08 | G1/2"X14 | 20 | 28 | 22 | |||||
| 4S-12 | G3/4"X14 | 22 | 32 | 30 | |||||
| 4S-16 | G1"X11 | 24 | 35 | 36 | |||||
Our high levels product quality,quick response 24/7 service will satisfy all of our clients.
PEHEL hydraulics is a manufacturer of hose fittings, hydraulic adapters, hose assembly, manifold block, hydraulic machine, flange fittings.
Our hydraulic products have a wide range applications, they include petrochemical, engineering machinery, injection molding machinery, mining equipment, agricultural machinery, ships, cars, machine manufacturing and custom hydraulic systems etc...
