PART NO. THREAD DIMENSIONS E F G A B C S1 S2 CK-14 M14X1.5 M14X1.5 M14X1.5 26.5 26.5 10.5 14 19 CK-14-22-39 M14X1.5 M22X1.5 M39X1.5 41 43 19 36 46 CK-16 M16X1.5 M16X1.5 M16X1.5 29.5 29.5 10 16 22 CK-18 M18X1.5 M18X1.5 M18X1.5 30.8 30.8 11.5 19 24 CK-22 M22X1.5 M22X1.5 M22X1.5 35.5 35.5 14 22 27 CK-24 M24X1.5 M24X1.5 M24X1.5 37 37 15 22 32 CK-30 M30X1.5 M30X1.5 M30X1.5 45.5 45.5 18.3 30 36 CK-33 M33X1.5 M33X1.5 M33X1.5 50 50 21.3 33 41 CK-39 M39X1.5 M39X1.5 M39X1.5 58.5 58.5 19 41 46
Metric Male/metric Male/metric Female
PEHEL Hydraulic Model: CK
QTY:
