PART NO. THREAD DIMENSIONS E F A B L S1 S2 2M-12 M12X1.5 M12X1.5 10 5 28 17 17 2M-14 M14X1.5 M14X1.5 11 5.5 29.5 19 19 2M-16 M16X1.5 M16X1.5 12 5.5 32 22 22 2M-16-18 M16X1.5 M18X1.5 12 5.5 33 22 24 2M-18 M18X1.5 M18X1.5 12 5.5 33 24 24 2M-18-16 M18X1.5 M16X1.5 12 5.5 32 24 22 2M-18-20 M18X1.5 M20X1.5 12 6.5 34.5 24 27 2M-18-22 M18X1.5 M22X1.5 12 6 35 24 27 2M-20 M20X1.5 M20X1.5 14 6.5 38.5 27 27 2M-20-18 M20X1.5 M18X1.5 14 5.5 37 27 24 2M-20-22 M20X1.5 M22X1.5 14 6 39 27 27 2M-22 M22X1.5 M22X1.5 14 6 39 27 27 2M-22-18 M22X1.5 M18X1.5 14 5.5 37 27 24 2M-22-20 M22X1.5 M20X1.5 14 6.5 38.5 27 27 2M-27 M27X1.5 M27X1.5 16 6 42.5 32 32 2M-30 M30X1.5 M30X1.5 18 6 46.5 36 36
Metric Male 60 Seat/metric Female 60 Cone
PEHEL Hydraulic Model: 2M
QTY:
