PARTNO. THREAD DIMENSIONS E F A B S1 1KT4-14-04SP M14X1.5 R1/4"X19 25 21 14 1KT4-14-06SP M14X1.5 R3/8"X19 25.5 23 16 1KT4-16-06SP M16X1.5 R3/8"X19 26 23 16 1KT4-18-06SP M18X1.5 R3/8"X19 28 24 19 1KT4-20-06SP M20X1.5 R3/8"X19 30 24 19 1KT4-22-06SP M22X1.5 R3/8"X19 31 25 22 1KT4-22-08SP M22X1.5 R1/2"X14 31 30 22 1KT4-24-08SP M24X1.5 R1/2"X14 33 29.5 22 1KT4-24-12SP M24X1.5 R3/4"X14 34 30.5 27 1KT4-30-12SP M30X1.5 R3/4"X14 39 31.5 30 1KT4-33-16SP M33X1.5 R1"X11 43.5 38 33
PEHEL/45 Metric Male 60 Cone/BSPT Male
PEHEL Hydraulic Model: 1KT4-SP
QTY:
45 Metric Male 60 Cone/BSPT Male
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: adapter
Thread Type 1: 45 Metric Male 60 Cone
Thread Type 2: BSPT Male
About the item:
1. 1KT4‑SP is 45‑degree elbow hydraulic adapter with metric male 60° cone and BSPT male tapered thread.
2. 60‑degree metal‑to‑metal cone sealing plus BSPT taper‑thread connection delivers leak‑proof performance for JIS‑standard hydraulic circuits.
3. Rich thread coverage includes M14×1.5‑M33×1.5 metric and R1/4"‑R1" BSPT for cross‑standard pipeline transition.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, offering good interchangeability and corrosion resistance.
5. 45‑angled layout optimizes piping routing, widely used for Japanese‑spec industrial and mobile hydraulic machinery.
