PART NO. FLANGE SIZE DIMENSIONS With bolt MPa A B d h M N 3000PSI FL-08W 1/2" 54 45.6 9 6.2 38.1 17.5 M8X25 34.5 FL-12W 3/4" 65 51.8 11 6.2 47.6 22.2 M10X30 FL-16W 1" 70 58.4 11 7.5 52.4 26.2 M10X30 FL-20W 1.1/4" 79 72.6 11 7.5 58.7 30.2 M10X30 27.6 FL-24W 1.1/2" 94 82.2 13.5 7.5 69.9 35.7 M12X35 20.7 FL-32W 2" 102 96.4 13.5 9 77.8 42.9 M12X35 FL-40W 2.1/2" 114 108.2 13.5 9 88.9 50.8 M12X40 17.2 FL-48W 3" 135 130.6 16.75 9 106.4 61.9 M16X50 13.8 6000PSI FS-08W 1/2" 56 47.2 9 7.2 40.5 18.2 M8X30 42 FS-12W 3/4" 71 60 11 8.2 50.8 23.8 M10X35 FS-16W 1" 81 69.9 13.5 9 57.2 27.8 M12X45 FS-20W 1.1/4" 95 77.2 13.5 9.8 66.6 31.8 M12X45 FS-24W 1.1/2" 113 95 17.5 12 79.3 36.5 M16X55 FS-32W 2" 133 113.8 22 12 96.8 44.5 M20X70 Color: White or Yellow
Finish: Zinc Plated
Transport Package: Plastic Papaer+ Carton Box+Wppden Pallet
Specification: sgs
Trademark: Pehel
Origin: China
HS Code: 73079900
Production Capacity: 1000 PCS/Day
1. Do you have products in stock?
Yes, for most porducts, we have.
2. Can you produce Non standard product?
Yes, we can produce products as your requirements (according to your sample or drawing)
3. What is your payment terms?
Regularly,our payment term is : 30% deposit advance the producing, 70% balance before shiping.
4. Can you accept LC payment?
Yes, we can.
5. Can you provide samples?
Yes.
PEHEL |Hydraulic SAE Flange Clamp | High Strength Carbon Steel Flange Clamp
PEHEL Hydraulic Model: FL-FS-W
QTY:
China SAE Hydraulic Flange
SAE Split Flange Clamp PFS
ISO 6162 SAE Flange Fittings ClampStandard: DIN Material: Medium Carbon Steel Connection: Female Surface Treatment: Chrome Head Type: Round Stock: Yes Material: Carbon steel, Stainless Steel, Aluminium, Brass
Brand: Pehel, OEM
Color: Silver
Connector Type: Clamp
Thread Type: SAE Flange Clamp
- SAE Standard Compliance Manufactured strictly per SAE standards, precise dimensions ensure great interchangeability with most hydraulic flange fittings for seamless assembly.
- High Strength Carbon Steel Structure Robust carbon steel body delivers powerful clamping force, stable performance under high pressure, shock and vibration in heavy-duty working conditions.
- Anti-leak & Anti-loosening Design Reliable clamping structure prevents connection separation, effectively eliminates fluid leakage for safe hydraulic pipeline operation.
- Corrosion Resistance & Easy Installation Quality surface treatment improves rust and oxidation resistance. Simple to install and disassemble, saving your labor and assembly time.
- Wide Application Scenarios Ideal for hydraulic machinery, construction equipment, mining machines and other industrial hydraulic systems. Each piece passes strict factory inspection for consistent bulk quality.
