PART NO. THREAD O-RING WELDTUBEO.D D DIMENSIONS E E L S1 5FW-04IN 9/16"X18 7.65X1.78 1/4" 18 17 5FW-06IN 11/16"X16 9.25X1.78 3/8" 20 19 5FW-08IN 13/16"X16 12.42X1.78 1/2" 22.6 22 5FW-10IN 1"X14 15.6X1.78 5/8" 27 27 5FW-12IN 1.3/16"X12 18.77X1.78 3/4" 30 32 5FW-16IN 1.7/16"X12 23.52X1.78 1" 31.8 38 5FW-20IN 1.11/16"X12 29.87X1.78 1.1/4" 34 46 5FW-24IN 2"X12 37.82X1.78 1.1/2" 35.5 55
Pehel | P5FW-IN| Hydraulic ORFS Male Flat / inch Socket-weld Tube Adapters
PEHEL Hydraulic Model: 5FW-IN
QTY:
ORFS Male Seal, ORFS Fittings Hydraulic Adapter
O-Ring Face Seal Fittings (ORFS) Hydraulic Adapter
O-ring face seal (ORFS)adapter fittings use a straight thread and have a machined groove in the face of the male fitting to accept an O ring (of either Buna N or Viton material).
ORFS fittings are one of the most recent families of hydraulic adapter fittings and offer excellent leak protection at high pressures. They are compatible with ORFS adapters from most manufacturers.Material: Carbon steel
Brand: Pehel
Color: Silver
Thread: Metric
Size: 1/4"-2"
About the items:
1.Durable hose fitting – designed for permanent welded pipe connections.
2. Reliable welded adapter – fusion-welded joint ensures zero-leak performance.
3. High-strength steel – withstands extreme pressures and vibration fatigue.
4. Compact design – eliminates thread connections for space-saving installation.
5. Versatile application – ideal for heavy-duty hydraulic and pneumatic systems.
