Male 74 Cone/SAE Flange

PEHEL Hydraulic Model: 1JFL-1JFS-W

QTY:

  • You May Also Like

  • PART NO. THREAD E FLANGE SIZE DIMENSIONS with Bolt MPa
    A B d H L M N
    3000PSI
    1JFL-08-08W 3/4"X16 1/2" 54 46 9 13 52 38.1 17.5 M8X30 34.5
    1JFL-10-08W 7/8"X14 1/2" 54 46 9 13 52 38.1 17.5 M8X30
    1JFL-12-12W 1.1/16"X12 3/4" 65 50 11 14 60 47.6 22.2 M10X30
    1JFL-16-16W 1.5/16"X12 1" 70 55 11 16 63 52.4 26.2 M10X30
    1JFL-20-20W 1.5/8"X12 1.1/4" 79 68 11 16 65 58.7 30.2 M10X30 27.6
    1JFL-16-20W 1.5/16"X12 1.1/4" 79 68 11 16 65 58.7 30.2 M10X30
    1JFL-24-24W 1.7/8"X12 1.1/2" 94 78 13.5 16 70 69.9 35.7 M12X35 20.7
    6000PSI
    1JFS-08-08W 3/4"X16 1/2" 56 48 9 16 60 40.5 18.2 M8X30 41.4
    1JFS-10-08W 7/8"X14 1/2" 56 48 9 16 60 40.5 18.2 M8X30
    1JFS-12-12W 1.1/16"X12 3/4" 71 60 11 19 73 50.8 23.8 M10X35
    1JFS-16-16W 1.5/16"X12 1" 81 70 13 24 82 57.2 27.8 M12X45
    1JFS-20-20W 1.5/8"X12 1.1/4" 95 78 15 27 92 66.6 31.8 M14X50
    1JFS-16-20W 1.5/16"X12 1.1/4" 95 78 15 27 92 66.6 31.8 M14X50
    1JFS-24-24W 1.7/8"X12 1.1/2" 113 95 17 30 96 79.3 36.5 M16X50
