并联数量NO. of stations
*01
02
03
04
05
06
07
08
长度 "A" 英寸 [毫米]"A" Length inch(mm)
4.00[101.6]
8.00[203.2]
12.00[304.8]
16.00[406.4]
20.00[508.0]
24.00[609.6]
28.00[711.2]
32.00[812.8]
铝材重量磅 [kg]opt. weight Alum.(kg)
6[3]
14[6]
22[10]
30[14]
38[17]
46[21]
52[24]
60[27]
钢材重量磅 [kg]Opt. weight steel(kg)
24[11]
46[21]
69[31]
90[41]
114[52]
135[61]
158[72]
180[82]
PEHEL | NG16 Hydraulic Oil Block| Lightweight aluminum alloy design
PEHEL Hydraulic Model: NG16 Block
QTY:
1. High-strength forged substrate, pressure-resistant & anti-fatigue
2. Full precision heat treatment, anti-deformation & zero leakage
3. Lightweight aluminum alloy design, reduce equipment weight & energy consumption
4. Steel manifold with high load capacity, suitable for high-pressure heavy-duty working conditions
5. Hard anodized /black oxide anti-rust surface, oil & corrosion resistant
6. Integrated forming without splicing, eliminate splicing leakage risk
1. Support non-standard size, special flow path & port customization
2. Compatible with stack valves, cartridge valves, solenoid directional valves
3. Metric/Imperial/G/SAE/DIN thread optional, worldwide applicable
4. Reserve auxiliary ports for pressure detection, unloading & overflow
5. Pre-machined thread holes & mounting holes, ready for assembly
