Metric Size Inch Size SAE Dash Size I.D O.D. Allowed Tolerance Max W.P Min B.P (Mpa) Min B.R (mm) W.T (g/m) Standard Standard(mm) One Layer Two Layer mm Inches Dash mm One Layer Two Layer mm Bar Psi Bar Psi One Layer Two Layer One Layer Two Layer One Layer Two Layer 6.3 1/4 04 6.3 12.7 13.3 ±0.10 275 3990 350 5070 110.0 140.0 40 40 160 290 8 5/16 05 7.9 14.9 14.9 ±0.10 250 2620 325 4710 100.0 130.0 55 50 215 340 10 3/8 06 9.5 15.9 16.7 ±0.10 225 3260 290 4200 90.0 116.0 65 70 240 400 12.5 1/2 08 12.7 19.8 19.8 ±0.15 175 2540 260 3770 70.0 105.0 85 80 310 560 16 5/8 10 15.9 23.3 23.3 ±0.15 140 2030 200 2900 56.0 80.0 115 130 410 630 19 3/4 12 18.9 26.5 26.0 ±0.15 120 1740 175 2540 48.0 70.0 140 160 500 750 25 1/1 16 25.4 34.0 33.0 ±0.20 100 1450 120 1740 40.0 48.0 180 220 650 1000
Pehel | Steel Wire Braid Resin Hose - Hydraulic Wire Braided Hose, Reinforced
PEHEL Hydraulic Model: SAE 100R7 / EN855 R7(STEEL WIRE BRAID)
QTY:
About the item:
- 1.High-pressure steel wire braid resin hose with multiple steel wire braid reinforcement layers delivers excellent burst strength for demanding hydraulic applications.
- 2.Flexible wire braided hose construction resists kinking and twisting, simplifying routing in tight machine spaces without sacrificing flow.
- 3.Smooth resin inner tube minimizes fluid friction and pressure drop, ensuring efficient media transfer in wire braid hydraulic hose assemblies.
- 4.Abrasion- and weather-resistant outer cover protects the braided resin hose from wear, oil, UV and harsh industrial environments.
- 5.Available in various inner diameters and lengths to OEM specifications, this steel wire braid hose is a direct replacement for standard hydraulic hose systems.
