Metric Size Inch Size SAE Dash Size I.D W.D O.D Max W.P Min B.P Min B.R W.T Standard(mm) Lenflex(mm) Standard(mm) Lenflex(mm) Standard(mm) Lenflex(mm) mm Inches Dash Min Max Min Max Max Min Max Max Min Max Mpa Bar Psi Mpa mm Kg/m 5 3/16 03 4.6 5.4 4.7 5.3 10.1 8.8 9.6 11.6 10.6 11.6 21.0 210 3045 84.0 45 0.18 6.3 1/4 04 6.2 7.0 6.2 6.8 11.0 10.0 11.0 13.2 12.2 13.2 21.0 210 3045 84.0 50 0.21 8 5/16 05 7.7 8.5 7.8 8.4 13.0 11.7 12.7 15.0 13.8 15.0 21.0 210 3045 84.0 55 0.26 10 3/8 06 9.3 10.1 9.5 10.1 15.0 13.9 14.9 17.0 16.0 17.0 21.0 210 3045 84.0 65 0.32 12.5 1/2 08 12.3 13.5 12.7 13.3 18.8 17.1 18.1 21.1 19.2 20.4 21.0 210 3045 84.0 90 0.42 16 5/8 10 15.5 16.7 15.8 16.4 23.6 21.8 23.0 25.9 24.0 25.2 21.0 210 3045 84.0 100 0.73 19 3/4 12 18.6 19.8 18.8 19.4 27.7 25.0 26.2 30.3 27.1 28.3 21.0 210 3045 84.0 120 0.93 25 1/1 16 25.0 26.4 25.0 25.6 35.6 32.4 33.6 38.6 35.0 36.2 21.0 210 3045 84.0 150 1.32
PEHEL |SAE 100R17 HYDRAULIC HOSE 21MPA Maximum Working Pressure| Abrasion Resistant Outer Layer
PEHEL Hydraulic Model: SAE 100R17
QTY:
Material: RUBBER
Brand: Pehel, OEM
Color: black
Thread Type: HYDRAULIC HOSE
1. High pressure resistance, burst-proof & long service life.
2. Excellent oil resistance, compatible with most hydraulic fluids.
3. Flexible yet sturdy, easy routing in tight machine spaces.
4. Weather & ozone resistant, anti-aging for outdoor use.
