PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH C S1 Per hundred weight Weight per case P12611A-02-04 G1/8"X28 6 4 10 14 1.9 350 P12611A-04-04 G1/4"X19 6 4 12 19 3 300 P12611A-06-06 G3/8"X19 10 6 13.5 22 5.4 200 P12611A-08-08 G1/2"X14 12 8 16 27 9.7 125 P12611A-12-12 G3/4"X14 20 12 18.5 32 17 120 P12611A-16-16 G1"X11 25 16 20.5 41 29 60 P12611A-20-20 G1.1/4"X11 32 20 20.5 50 46 40 P12611A-24-24 G1.1/2"X11 40 24 23 55 67.7 25 P12611A-32-32 G2"X11 50 32 25.5 70 15
PEHEL/BSP Male Double Use for 60º Cone Seat or Bonded Seal
PEHEL Hydraulic Model: P12611A
QTY:
Bsp Male Double Use for 60o Cone Seat or Bonded Seal- 12611A Hose Fitting Fitting
BSP Male Double Use for 60º Cone Seat or Bonded Seal
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: HSOE FITTING
Thread Type: BSP Male 60º Cone Seat
ABOUT THE ITEM:
1. 12611A is straight crimp‑style hydraulic hose fitting with BSP male double‑use end for 60° cone seat or bonded‑seal installation.
2. Dual‑seal design supports metal‑to‑metal 60‑degree cone sealing or bonded‑gasket sealing for flexible leak‑free assembly.
3. Complete size range covers G1/8"‑G2" BSP threads, matching hose bore DN6‑DN50 for diverse high‑pressure hose assemblies.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, compliant with BSP standard for reliable interchangeability.
5. Heavy‑duty hose end widely used for crimped hose assemblies on construction, agricultural and mobile hydraulic machinery.
