PART NO.
THREAD DIMENSIONS E F C1 C2 S1 S2 L P3B-02 G 1/8" X28 G 1/8" X28 5.5 5.5 14 14 20 P3B-02-04 G 1/8" X28 G1/4" X19 5.5 5.5 14 19 23 P3B-04 G1/4" X19 G1/4" X19 5.5 5.5 19 19 25 P3B-04-06 G1/4" X19 G3/8" X19 5.5 6.3 19 22 26 P3B-04-08 G1/4" X19 G1/2" X14 5.5 7.5 19 27 28 P3B-06 G3/8" X19 G3/8" X19 6.3 6.3 22 22 29 P3B-06-08 G3/8" X19 G1/2" X14 6.3 7.5 22 27 30 P3B-08 G1/2" X14 G1/2" X14 7.5 7.5 27 27 32 P3B-08-10 G1/2" X14 G5/8" X14 7.5 9.5 27 30 32.5 P3B-08-12 G1/2" X14 G3/4" X14 7.5 10.9 27 32 33 P3B-10 G5/8" X14 G5/8" X14 9.5 9.5 30 30 33 P3B-10-12 G5/8" X14 G3/4" X14 9.5 10.9 30 32 33.5 P3B-12 G3/4" X14 G3/4" X14 10.9 10.9 32 32 34 P3B-12-16 G3/4" X14 G1" X11 10.9 11.7 32 41 35.5 P3B-16 G1" X11 G1" X11 11.7 11.7 41 41 36.5 P3B-20 G1.1/4"X11 G1.1/4"X11 11 11 50 50 42 P3B-24 G1.1/2"X11 G1.1/2"X11 13 13 55 55 43 P3B-32 G2" X11 G2" X11 16 16 70 70 49
Pehel/3B/Straight Female BSP 60deg Cone-Female BSP 60deg Cone Swivel Adapter
PEHEL Hydraulic Model: 2-P3B
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Straight
Thread Type: BSP 60° Cone
About the item:
1.Precision-machined straight hydraulic adapters with concentric thread alignment, eliminating flow turbulence and pressure drop in high-flow hydraulic loops.
2.Zinc-plated carbon steel body with salt spray resistance up to 240 hours, effectively preventing corrosion in outdoor and humid working environments.
3.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss.
