PART NO.
THREAD DIMENSIONS E A S2 L P9A-04 G1/4"-19 4 19 15 -06 G3/8"-19 5 22 16 -08 G1/2"-14 6 27 18 -10 G5/8"-14 8 30 19 -12 G3/4"-14 9 32 20 -16 G 1"-11 10.5 41 21 -20 G1.1/4"-11 10 50 23.5 -24 G1.1/2"-11 11 55 25 -32 G 2"-11 15 70 27
PEHEL/BSP FEMALE MULTISEAL PLUG-SWIVEL
PEHEL Hydraulic Model: PO9A
QTY:
BSP FEMALE MULTISEAL PLUG-SWIVEL
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: PLUG
Thread Type: BSP FEMALE MULTISEAL
About the item:
1. 9A is BSP female multiseal swivel plug, designed to block off BSP male ports in hydraulic pipelines.
2. Multiseal 60‑degree cone swivel structure enables free rotation while maintaining stable leak‑proof sealing.
3. Comprehensive BSP thread sizes range from G1/4" to G2", covering mainstream British‑standard hydraulic port specifications.
4. Precisely CNC‑machined carbon‑steel body with zinc‑plated finish, delivering good interchangeability and anti‑corrosion performance.
5. Hex‑head design for convenient wrench operation, widely used for port sealing and thread protection on industrial and mobile hydraulic equipment.
