PART NO. BOLT HOSE BORE DIMENSIONS DN DASH d D H Per hundred weight Weight per case P70011-12-04 M12X1.5 6 4 12 20 12 2.2 600 70011-12-05 M12X1.5 8 5 12 20 12 2 500 70011-12-06 M12X1.5 10 6 12 20 12 2.5 500 70011-14-04 M14X1.5 6 4 14 24 14 3.3 600 70011-14-05 M14X1.5 8 5 14 24 14 3.2 500 70011-14-06 M14X1.5 10 6 14 24 14 3.5 500 70011-16-06 M16X1.5 10 6 16 28 16 4.7 300 70011-18-06 M18X1.5 10 6 18 32 20 6.8 250 70011-18-08 M18X1.5 12 8 18 32 20 7.2 200 70011-22-08 M22X1.5 12 8 22 39 25 13.1 150 70011-22-10 M22X1.5 16 10 22 39 25 13.6 150 70011-26-12 M26X1.5 20 12 26 46 30 22.9 100
Metric Banjo Fitting DIN 7642 for Hydraulic Systems – Pehel
PEHEL Hydraulic Model: P70011
QTY:
Metric Banjo Bolt Hydraulic Fitting 70011
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.Compact banjo design per DIN 7642 – the metric banjo fitting connects hydraulic lines at right angles to pumps, motors and cylinders, saving space in tight installations.
- 2.O-ring radial sealing – DIN 7642 metric banjo connectors use a radial O-ring for leak-free performance without overtightening the banjo bolt.
- 3.Metric thread compatibility – precision metric threads make this hydraulic banjo fitting a direct, drop-in replacement for standard European equipment.
- 4.Material options – silver color zinc plated carbon steel for everyday hydraulics, or stainless steel metric banjo fittings for washdown and marine environments.
- 5.Vibration-resistant assembly – the one-piece banjo construction resists loosening from machine vibration, keeping hydraulic pressure stable over long service life.
