PART NO. E (THREAD E) HOSE BORE (DN) HOSE BORE (DASH) DIMENSIONS (A) DIMENSIONS (B) DIMENSIONS (H) DIMENSIONS (S1) Per hundred weight Weight per case 26791-06-06PK 9/16"X18 10 6 61 39 39 19 10.6 80 26791-08-06PK 3/4"X16 10 6 61 39 40 24 8.8 80 26791-08-08PK 3/4"X16 12 8 72.5 44 47 24 18.2 0 26791-10-10PK 7/8"X14 16 10 93 55.9 52.5 27 26.5 40 26791-12-12PK 1.1/16"X12 20 12 103.5 63.9 63 32 35.8 30 26791-16-16PK 1.5/16"X12 25 16 122 77 70 38 67.1 20 26791-20-20PK 1.5/8"X12 32 20 137.8 90.8 84.5 50 116.8 15 26791-24-24PK 1.7/8"X12 40 24 148 109.6 101.5 60 168.2 10 26791-32-32PK 2.1/2"X12 50 32 178 130.8 122.5 73 4 26791-06-04PK 9/16"X18 6 4 52.5 32.9 33 19 6.9 100 26791-10-08PK 7/8"X14 12 8 72.5 44 48 27 19.3 30
PEHEL | 90° JIC Female 74° Cone Seat Fitting, Hydraulic Elbow Fitting
PEHEL Hydraulic Model: 26791-PK
QTY:
90 Elbow Fitting JIC Female Hydraulic Pipe Fitting 26791 Winner Hydraulic Carbon Steel Pipe Fitting
Type: 90° JIC Female 74° Cone Seat Fitting
Angle: 90° Elbow
Thread: JIC Female
Sealing: 74° Cone Seat
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc-plated
1.90° JIC female 74° cone seat fitting, designed as an angled hydraulic fitting with a 74° cone sealing surface.
2.Female JIC threads allow secure engagement with corresponding male threaded components.
3.The 74° cone seat provides metal-to-metal sealing through line contact when mated with a matching cone.
4.90° elbow configuration enables directional change of fluid flow in confined spaces.
5.Manufactured from high-strength carbon steel with anti-rust surface treatment for durability.
