THREAD TUBE O.D. DIMENSIONS PART NO. MPa E,F,G,H D1,D2,D3,D4 I1 L1 S1 S2 XC-12 M12X1.5 6 12 27 12 14 31.5 L XC-14 M14X1.5 8 14 29 12 17 XC-16 M16X1.5 10 15 30 14 19 XC-18 M18X1.5 12 17 32 17 22 XC-22 M22X1.5 15 21 36 19 27 XC-26 M26X1.5 18 23.5 40 24 32 XC-30 M30X2 22 27.5 44 27 36 16 L XC-36 M36X2 28 30.5 47 36 41 XC-45 M45X2 35 34.5 56 41 50 XC-52 M52X2 42 40 63 50 60 XD-14 M14X1.5 6 16 31 12 17
63 SXD-16 M16X1.5 8 17 32 14 19 XD-18 M18X1.5 10 17.5 34 17 22 XD-20 M20X1.5 12 21.5 38 17 24 XD-22 M22X1.5 14 22 40 19 27 XD-24 M24X1.5 16 24.5 43 24 30 40 S XD-30 M30X2 20 26.5 48 27 36 XD-36 M36X2 25 30 54 36 46 XD-42 M42X2 30 35.5 62 41 50 XD-52 M52X2 38 41 72 50 60 31.5 S
PEHEL | Metric Male Cross Fitting, 4‑Way Hydraulic Adapter with Male Metric Threads
PEHEL Hydraulic Model: PXC PXD/PXC-RN PXD-RN
QTY:
Type: Cross Fitting / 4‑Way Adapter
Thread Type: Metric Male
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated or anti‑rust coated
About the item:
1.Metric male cross fitting designed as a four‑way connector for dividing or combining fluid flow in hydraulic and pneumatic systems.
2.All four ports feature male metric threads, enabling direct connection to female metric threaded components.
3.The cross configuration allows equal distribution or collection of fluid in multiple directions within a compact footprint.
4.Manufactured from high‑strength carbon steel with anti‑rust surface treatment for reliable performance in demanding environments.
5.Precision machined threads ensure consistent fit and leak‑free operation with standard metric threaded fittings.
